LRS Series LED Power Supply | IP20 Non-Waterproof | 35W–600W
LRS Series LED Power Supply | IP20 Non-Waterproof | 35W–600W
LRS Series LED Power Supply | IP20 Non-Waterproof | 35W–600W
LRS Series LED Power Supply | IP20 Non-Waterproof | 35W–600W
LRS Series LED Power Supply | IP20 Non-Waterproof | 35W–600W
LRS Series LED Power Supply | IP20 Non-Waterproof | 35W–600W
LRS Series LED Power Supply | IP20 Non-Waterproof | 35W–600W
LRS Series LED Power Supply | IP20 Non-Waterproof | 35W–600W

LRS Series LED Power Supply | IP20 Non-Waterproof | 35W–600W

★ ★ ★ ★ ★
4.8 | 100+ reviews
✓ Verified
10 customers are viewing this product
$33.53
$33.53
Vendor: CIRC
SKU: LRS-35-12
Product Type: LED Power Supply

Option:

Output Voltage: 12V
Rated Power: 35W
Technical Specifications
|
    • Series: LRS (IP20 Non-Waterproof)
    • Input Voltage: 85–264V AC (LRS-35 to LRS-100) / 110V/220V Select By Switch (LRS-150 to LRS-600)
    • Output Voltage: 5V / 12V / 24V DC
    • Power Range: 35W – 600W (model dependent)
    • IP Rating: IP20 (Indoor Non-Waterproof)
    • Power Factor Correction: Non-PFC
    • Profile: Ultra Compact, 1U Low Profile
    • Input Surge Protection: 300VAC
    • No Load Power Consumption: 0.2W – 0.75W
    • Vibration Rating: 5G
    • Operating Temperature: Up to 70°C
    • Operating Altitude: Up to 5,000 meters
    • Certifications: UL / CE / CB / TUV / CCC
    • Safety Standards: IEC/EN60335-1 (PD3) / IEC/EN61558-1 & -2-16 / IEC/EN/UL60950-1 / GB4943
    • Warranty: 3 Years
Availability: In Stock (1250)
Add $400.00 more to get free standard shipping.

Estimated delivery: 24/08/2025 - 29/08/2025.

Ask An Expert
Subtotal: $33.53

⚡ Fast Delivery: USPS Priority Mail

Free Shipping

Free Returns

Learn More.
LRS Series LED Power Supply | IP20 Non-Waterproof | 35W–600W

LRS Series LED Power Supply | IP20 Non-Waterproof | 35W–600W

$33.53
LRS Series LED Power Supply | IP20 Non-Waterproof | 35W–600W
LRS Series LED Power Supply | IP20 Non-Waterproof | 35W–600W
LRS Series LED Power Supply | IP20 Non-Waterproof | 35W–600W
LRS Series LED Power Supply | IP20 Non-Waterproof | 35W–600W
LRS Series LED Power Supply | IP20 Non-Waterproof | 35W–600W
LRS Series LED Power Supply | IP20 Non-Waterproof | 35W–600W
LRS Series LED Power Supply | IP20 Non-Waterproof | 35W–600W
LRS Series LED Power Supply | IP20 Non-Waterproof | 35W–600W

LRS Series LED Power Supply | IP20 Non-Waterproof | 35W–600W

$33.53
Output Voltage: 12V
Rated Power: 35W
Additional Information
Additional Information
x
At Circ Lighting, we specialize in high-quality architectural and commercial lighting solutions designed to enhance spaces with both functionality and style. Our products combine advanced technology with modern aesthetics to meet the needs of designers, builders, and lighting professionals across the United States. Whether you're planning a residential project or a large-scale commercial installation, we are committed to delivering reliable, innovative lighting with excellent customer support.
Shipping & Return
Shipping & Return
x

Returns Policy

We offer fast and secure shipping across the United States. Orders are typically processed within 7–10 business days and shipped via trusted carriers such as UPS, FedEx, or USPS. Shipping times vary based on destination and selected shipping method.

Shipping

If you’re not completely satisfied with your purchase, you may return it within 14 days of delivery. To be eligible for a return, the item must be unused, in its original packaging, and in resalable condition. Please contact our support team at info@circlighting.com to initiate a return or for further assistance.

Description
Description
x

CIRC LRS Series LED Power Supply | IP20 Non-Waterproof (35W–600W)

The CIRC LRS Series LED Power Supply is a highly reliable and cost-effective indoor power solution designed specifically for LED strip lighting systems and general low-voltage applications. Built with a compact ultra-slim 1U low-profile design, this series is ideal for installations where space is limited but stable performance is essential.

Available in 5V, 12V, and 24V DC output options, and ranging from 35W to 600W, the LRS series provides flexible power solutions for small to large-scale LED lighting projects. Its efficient design ensures stable DC output with low energy loss, making it one of the most widely used LED drivers in professional lighting installations.

Key Features

  • Economical non-PFC design for cost-effective installations
  • Ultra-compact 1U low-profile housing for tight spaces
  • Wide 85–264V AC input range
  • 300VAC surge protection for enhanced durability
  • Very low no-load power consumption (0.2W–0.75W)
  • Operates up to 70°C ambient temperature
  • 5G vibration resistant for stable performance
  • High altitude operation up to 5000 meters
  • Fully certified for global safety standards
  • Suitable for LED strips, signage, and general DC systems

Certifications & Warranty

Feature Details
Certifications UL, CE, CB, TUV, CCC
Warranty 3 Years
Safety Standards IEC/EN60335-1 (PD3), IEC/EN61558-1 & -2-16, IEC/EN/UL60950-1, GB4943
Protection Type IP20 (Indoor Dry Use Only)

Product Specifications Overview

Feature Details
Product Series CIRC LRS Series
Power Range 35W to 600W
Output Voltages 5V / 12V / 24V DC
Input Voltage 85–264V AC (select models 110V/220V switchable)
Design Type Non-PFC, ultra-compact
Cooling Free air convection
Usage Indoor LED lighting systems

Model & Power Selection

Model Rated Power Input Voltage
LRS-35-12 35W 85–264V AC
LRS-35-24 35W 85–264V AC
LRS-50-5 50W 85–264V AC
LRS-50-12 50W 85–264V AC
LRS-50-24 50W 85–264V AC
LRS-75-5 75W 85–264V AC
LRS-75-12 75W 85–264V AC
LRS-75-24 75W 85–264V AC
LRS-100-5 100W 85–264V AC
LRS-100-12 100W 85–264V AC
LRS-100-24 100W 85–264V AC
LRS-150-12 150W 110V / 220V switchable
LRS-150-24 150W 110V / 220V switchable
LRS-200-5 200W 85–264V AC
LRS-200-12 200W 85–264V AC
LRS-200-24 200W 85–264V AC
LRS-350-5 350W 85–264V AC
LRS-350-12 350W 85–264V AC
LRS-350-24 350W 85–264V AC
LRS-450-5 450W 85–264V AC
LRS-450-12 450W 85–264V AC
LRS-450-24 450W 85–264V AC
LRS-600-5 600W 85–264V AC
LRS-600-12 600W 85–264V AC
LRS-600-24 600W 85–264V AC

Packaging Information

Feature Details
Unit Weight 0.23 kg – 0.95 kg (depending on model)
Packing Range 12 pcs – 60 pcs per carton
Carton Weight Range Approx. 10.9 kg – 15.4 kg
Volume 0.75 CUFT – 0.92 CUFT

Best Applications

LED Strip Lighting Systems

Stable and efficient power for COB, RGB, RGBW, and CCT LED strips.

Architectural Lighting

Ideal for ceiling coves, wall lighting, and decorative installations.

Signage & Display Systems

Reliable power source for illuminated signs and branding.

Indoor Commercial Projects

Perfect for retail stores, offices, and hospitality lighting systems.

Reliable Power for Professional LED Installations

The CIRC LRS Series LED Power Supply delivers trusted performance, compact design, and global safety certification, making it one of the most dependable choices for LED lighting systems worldwide. It ensures stable voltage output, long service life, and safe operation for all indoor lighting projects.
