YG042NI60

Product Description: Circlighting High-Performance Industrial & Commercial LED Luminaires (YG042 Series)

The Circlighting YG042 Series encompasses a range of high-performance LED luminaires, engineered for robust and energy-efficient lighting in demanding industrial and commercial environments. Designed with high ingress protection (IP65) and impressive luminous efficacy, these fixtures offer bright, reliable, and adaptable illumination. Whether requiring fixed wattage solutions or advanced tunable power and dimming capabilities, the YG042 series provides versatile options for warehouses, factories, outdoor areas, and large-scale facilities.

YG042NI Series: High-Efficacy Fixed Wattage LED Luminaires

The Circlighting YG042NI Series provides powerful and efficient fixed-wattage LED luminaires, ideal for general illumination in large areas. With a high luminous efficacy of 120 LM/W and a robust IP65 rating, these fixtures deliver consistent, bright light suitable for challenging environments. They also feature selectable color temperatures for tailored ambiance.

Available Models & Specifications:

• YG042NI60:

  • Power (Wattage): 60W

  • Lumen Output: >7200LM (calculated from 120LM/W)

  • Luminous Efficacy: 120LM/W

  • CRI: >80

  • IP Rating: 65

  • Selectable CCT: 3000K / 4000K / 5000K / 6000K (4 options)

• YG042NI80:

  • Power (Wattage): 80W

  • Lumen Output: >9600LM (calculated from 120LM/W)

  • Luminous Efficacy: 120LM/W

  • CRI: >80

  • IP Rating: 65

  • Selectable CCT: 3000K / 4000K / 5000K / 6000K (Consistent with series features)

• YG042NI100:

  • Power (Wattage): 100W

  • Lumen Output: >12000LM (calculated from 120LM/W)

  • Luminous Efficacy: 120LM/W

  • CRI: >80

  • IP Rating: 65

  • Selectable CCT: 3000K / 4000K / 5000K / 6000K (Consistent with series features)

• YG042NI120:

  • Power (Wattage): 120W

  • Lumen Output: >14400LM (calculated from 120LM/W)

  • Luminous Efficacy: 120LM/W

  • CRI: >80

  • IP Rating: 65

  • Selectable CCT: 3000K / 4000K / 5000K / 6000K (Consistent with series features)

Key Features (Common to YG042NI Series):

• High Luminous Efficacy: Delivers over 120 lumens per watt, ensuring excellent light output for reduced energy consumption.

• Wet Location & Dust-Tight (IP65): Provides complete protection against dust and water jets, suitable for challenging environments.

• Selectable Color Temperature (CCT): Offers four distinct white light options (3000K Warm White to 6000K Daylight), allowing customization of ambiance.

• Good Color Rendering: A CRI of >80 ensures natural appearance of illuminated objects and spaces.

Benefits & Applications:

• Robust & Durable: Engineered for long-lasting performance in industrial and commercial settings.

• Energy Efficient: Significant energy savings due to high efficacy.

• Versatile Illumination: Adaptable CCT for different functional and aesthetic needs.

• Ideal for: Warehouses, factories, gymnasiums, large retail spaces, and outdoor canopy lighting.

YG042NIT Series: Tunable Wattage Multi-CCT Dimmable LED Luminaires

The Circlighting YG042NIT Series introduces advanced functionality with field-selectable wattage options, multi-selectable color temperatures, and integrated dimming capabilities. These luminaires offer maximum flexibility and control for optimizing light levels and energy usage in various applications.

Available Models & Specifications:

• YG042NIT4060-S-3C-DM:

  • Power (Tunable Wattage): 40W / 50W / 60W

  • Lumen Output (Approx.): >4800LM (40W) to >7200LM (60W) (calculated from 120LM/W)

  • Luminous Efficacy: 120LM/W

  • CRI: >80

  • IP Rating: 65

  • Selectable CCT: 3000K / 4000K / 5000K / 6000K (4 options via switch control)

  • Dimming: Dimmable (implied by "-DM" suffix)

• YG042NIT80120-S-3C-DM:

  • Power (Tunable Wattage): 80W / 100W / 120W

  • Lumen Output (Approx.): >9600LM (80W) to >14400LM (120W) (calculated from 120LM/W)

  • Luminous Efficacy: 120LM/W

  • CRI: >80

  • IP Rating: 65

  • Selectable CCT: 3000K / 4000K / 5000K / 6000K (Consistent with series features, via switch control)

  • Dimming: Dimmable (implied by "-DM" suffix)

Key Features (Common to YG042NIT Series):

• Field-Selectable Wattage: Allows users to choose desired power output for optimal light levels and energy management.

• High Luminous Efficacy: Maintains over 120 lumens per watt for efficient operation.

• Wet Location & Dust-Tight (IP65): Robust construction ensures durability in demanding environments.

• Multi-Selectable CCT: Offers 4 selectable color temperatures to match various application requirements.

• Dimmable Functionality: Provides flexibility for brightness control.

• Switch Control: CCT selection is managed via a switch on the fixture.

Benefits & Applications:

• Maximized Flexibility: Tailor light output and color temperature on-site to exact needs, reducing inventory.

• Optimized Energy Use: Fine-tune power consumption based on specific lighting requirements.

• Enhanced Control: Integrated dimming for dynamic lighting and energy savings.

• Ideal for: Warehouses, industrial facilities, distribution centers, and high-ceiling applications where light level and color temperature customization are beneficial.

Circlighting High-Efficacy Tunable & Dimmable LED Luminaire

This high-performance LED luminaire offers advanced functionality with selectable wattage and color temperature options, coupled with precise 0-10V dimming. Its superior luminous efficacy makes it an exceptionally energy-efficient choice for general lighting in challenging environments.

Available Models & Specifications:

• (Model/Size not specified):

  • Power (Tunable Wattage): 40W / 30W / 20W

  • Lumen Output (Approx.): >2600LM (20W) to >5200LM (40W) (calculated from 130LM/W)

  • Luminous Efficacy: 130LM/W

  • Dimming: 0-10V Dimmable

  • CRI: >80

  • IP Rating: 65

  • Selectable CCT: 3500K / 4000K / 5000K (3 options)

Key Features:

• Ultra-High Luminous Efficacy: Achieves an impressive 130 lumens per watt, setting a high standard for energy efficiency.

• Field-Selectable Wattage: Allows on-site adjustment between 20W, 30W, and 40W for precise light level management.

• 0-10V Dimming: Provides smooth and responsive dimming control for energy savings and desired ambiance.

• Wet Location & Dust-Tight (IP65): Ensures robust performance in harsh or damp conditions.

• Multi-Selectable CCT: Offers 3 selectable white light color temperatures for versatility.

• Good Color Rendering: A CRI of >80 ensures natural lighting quality.

Benefits & Applications:

• Maximized Energy Savings: Top-tier efficacy significantly reduces operational costs.

• Precise Control: Fine-tune brightness and power consumption with 0-10V dimming and selectable wattages.

• Optimized Ambiance: Choose the ideal color temperature for various tasks or environments.

• Durable & Reliable: Built for demanding conditions with IP65 protection.

• Ideal for: Warehouses, manufacturing plants, high-ceiling commercial spaces, and areas requiring exceptional energy efficiency and adaptable lighting.
