30W-24W-18W

Product Description: High-Efficacy Tunable Wattage LED Luminaires with 0-10V Dimming (Circlighting Unnamed Series)

This series of Circlighting LED Luminaires offers versatile and energy-efficient lighting solutions designed for robust performance in industrial, commercial, and challenging environments. Featuring a high luminous efficacy of 120 lumens per watt, these fixtures deliver powerful illumination while significantly reducing energy consumption. Each model provides multiple field-selectable wattage options and selectable color temperatures, giving users precise control over light levels and ambiance. With integrated 0-10V dimming and a durable IP65 rating, these luminaires are ideal for applications requiring adaptable and reliable lighting in demanding conditions.

Available Models & Specifications:

(Note: Specific model numbers and physical dimensions for these luminaires are not provided.)

• Variant 1:

  • Power (Tunable Wattage): 30W / 24W / 18W (Field-selectable)

  • Lumen Output (Approx.): >2,160LM (18W) to >3,600LM (30W) (calculated from 120LM/W)

  • Luminous Efficacy: 120LM/W

  • Dimming: 0-10V Dimmable

  • CRI (Color Rendering Index): >80

  • IP Rating: IP65

  • Selectable CCT: 3500K (Neutral White) / 4000K (Cool White) / 5000K (Daylight)

• Variant 2:

  • Power (Tunable Wattage): 50W / 40W / 30W (Field-selectable)

  • Lumen Output (Approx.): >3,600LM (30W) to >6,000LM (50W) (calculated from 120LM/W)

  • Luminous Efficacy: 120LM/W

  • Dimming: 0-10V Dimmable

  • CRI: >80

  • IP Rating: IP65

  • Selectable CCT: 3500K / 4000K / 5000K (Consistent with series features)

• Variant 3:

  • Power (Tunable Wattage): 100W / 80W / 60W (Field-selectable)

  • Lumen Output (Approx.): >7,200LM (60W) to >12,000LM (100W) (calculated from 120LM/W)

  • Luminous Efficacy: 120LM/W

  • Dimming: 0-10V Dimmable

  • CRI: >80

  • IP Rating: IP65

  • Selectable CCT: 3500K / 4000K / 5000K (Consistent with series features)

Key Features (Common to Series):

• High Luminous Efficacy: Delivers an impressive 120 lumens per watt, ensuring powerful illumination with high energy efficiency.

• Field-Selectable Wattage: Offers three distinct power settings per model, allowing for precise adjustment of light output to meet specific project requirements and optimize energy consumption.

• 0-10V Dimmable: Provides smooth and responsive dimming control, enabling dynamic light level adjustments and further energy savings.

• Wet Location & Dust-Tight (IP65): The robust IP65 rating signifies complete protection against dust ingress and resistance to low-pressure water jets, making these luminaires suitable for challenging indoor and outdoor covered environments.

• Multi-Selectable Color Temperature (CCT): Offers three versatile white light options (3500K Neutral White, 4000K Cool White, and 5000K Daylight), allowing for customization of the lighting ambiance.

• Good Color Rendering: A CRI of >80 ensures that colors appear natural and vibrant under illumination.

• Versatile Design: (Likely industrial or high-bay type luminaires, suitable for various mounting methods, though specific form factor is not provided.)

Benefits & Applications:

• Exceptional Energy Savings: Reduce electricity consumption and operating costs significantly due to high efficacy and dimmable features.

• Customizable Illumination: Easily adjust brightness and color temperature on-site to suit various tasks, preferences, and environmental conditions.

• Robust & Reliable Performance: Built to withstand harsh conditions, ensuring long-term durability and minimal maintenance.

• Flexible Deployment: Adaptable to a wide range of applications thanks to tunable wattage and high IP rating.

• Ideal for: Warehouses, factories, gymnasiums, large commercial spaces, parking garages, utility rooms, and other industrial or outdoor covered areas requiring high-performance, flexible, and durable lighting.
